Non-Metallic DC Clips (Flat Conductor)

Non-Metallic DC Clips (Flat Conductor)

SKU: PCxxxx Category: Tag:
Clear
Download PDF

SKU: PCxxxx Category: Tag:

Product Information:

Non-Metallic DC Clips (Flat Conductor) are available in six colours to match bare and PVC copper and aluminium tapes.

Features:

Material: UV Stabilised Polypropylene
Tightening torque: 8Nm

More Information:

When choosing a connector it is important to ensure:

  • The connector is mechanically robust.
  • The connector is selected according to its application.
  • The connector is rated for its application.
  • To avoid bimetallic corrosion-use a bimetallic connector (do not connect bare copper directly to bare aluminium, or have water run-off from copper, fall into aluminium).

Galvanic corrosion happens when there is a potential difference between dissimilar metals:

  • When the materials are in contact in the presence of an electrolyte, corrosion occurs. One metal becomes the anode, the other the cathode. The anode will tend to go into solution and therefore corrode. The electrolyte can be water with impurities from the air.
  • In the instance of water run-off from copper- the water carries fine copper corrosion particles which, when they drop on to aluminium or zinc, may result in corrosion. The direct contact of the dissimilar metals are not required for corrosion to occur in such a case.
CONDUCTOR SIZE (mm)
CONDUCTOR TYPECOLOUR
WEIGHT (kg)
PART NO.
20 x 3
BareBrown
0.01
PCBN203B
20 x 3
BareGrey
0.01
PCGY203B
25 x 3
BareBrown
0.01
PCBN253B
25 x 3
BareGrey
0.01
PCGY253B
50 x 6
BareBrown
0.01
PCBN506B
25 x 3
PVCBrown
0.01
PCBN253P
25 x 3
PVCBlack
0.01
PCBL253P
25 x 3
PVCGrey
0.01
PCGY253P
25 x 3
PVCGreen
0.01
PCGN253P
25 x 3
PVCStone
0.01
PCST253P
25 x 3
PVCWhite
0.01
PCWH253P

Fixings:
