BS:EN 62305 Metallic DC Clips (Flat Conductor)

BS:EN 62305 Metallic DC Clips (Flat Conductor)

SKU: MDxxxx Category: Tag:
Clear
Download PDF

SKU: MDxxxx Category: Tag:

Product Information:

BS:EN 62305 Metallic DC Clips for securing lightning conductors to flat surfaces. They are suitable for use in Earthing and Lightning Protection Applications.

Features:

Material: High-Quality Copper Alloy/Aluminium
Standard: BS:EN 62305

More Information:

More Information:

When choosing a connector it is important to ensure:

  • The connector is mechanically robust.
  • The connector is selected according to its application.
  • The connector is rated for its application.
  • To avoid bimetallic corrosion-use a bimetallic connector (do not connect bare copper directly to bare aluminium, or have water run-off from copper, fall into aluminium).

Galvanic corrosion happens when there is a potential difference between dissimilar metals:

  • When the materials are in contact in the presence of an electrolyte, corrosion occurs. One metal becomes the anode, the other the cathode. The anode will tend to go into solution and therefore corrode. The electrolyte can be water with impurities from the air.
  • In the instance of water run-off from copper- the water carries fine copper corrosion particles which, when they drop on to aluminium or zinc, may result in corrosion. The direct contact of the dissimilar metals are not required for corrosion to occur in such a case.
CONDUCTOR SIZE (mm)
CONDUCTOR TYPE
WEIGHT (kg)
PART NO.
25 x 3
Bare Copper
0.047
MDCF253
25 x 6
Bare Copper
0.057
MDCF256
31 x 6
Bare Copper
0.061
MDCF316
40 x 4
Bare Copper
0.062
MDCF404
50 x 6
Bare Copper
0.077
MDCF506
25 x 3
PVC Copper
0.055
MDCF253P
25 x 6
PVC Copper
0.064
MDCF256P
31 x 6
PVC Copper
0.069
MDCF316P
40 x 4
PVC Copper
0.071
MDCF404P
50 x 6
PVC Copper
0.084
MDCF506P
25 x 3
Aluminium
0.017
MDAF253
25 x 3
PVC Aluminium
0.020
MDAF253P
