Insulated Separation Bars

Insulated Separation Bars

SKU: KM-979xxx Category: Tag:
Download PDF

SKU: KM-979xxx Category: Tag:

Product Information:

Insulated Separation Bars maintain the separation distance between the lightning protection conductor and the object being protected. Generally used in the application of Isolated Air Termination Systems.

Features:

Material: GRP

More Information:

M16 threaded bars available on request.
Kingsmill can supply Isolated Lightning Protection Systems, utilizing Insulated Spacer Bars in conjunction with Air Terminals and Conductor Supports.
Such systems are project-specific and better options might be available. Please contact us for advice.

Isolated Systems can be used where roof space is limited but space permits their use.

DESCRIPTION
DIMENSIONS (mm)
[A x B]
WEIGHT (kg)
PART NO.
750mm Separation Bar
750
638
0.48
KM97900729
1000mm Separation Bar
1000
888
0.57
KM97900029
1500mm Separation Bar
1500
1388
0.60
KM97901529
2000mm Separation Bar
2000
1888
0.80
KM97920029
