Product Information:

Adhesive Clips are used to affix lightning protection where no mechanical fixing method can be achieved or allowed. The base has a threaded hole and is supplied with a fixing screw to suit our Non-Metallic DC Clip. The base is fixed using the adhesive peel-off strip and must be applied to a clean and dust-free surface.

Please use the Surface Primer to clean the surface (Part No. SP01).

Features:

Material: UV stabilised polypropylene
Available in different colours.

More Information:

We recommend the use of a suitable Surface Primer to clean the surface that the Adhesive Clip is being affixed to.

When choosing a connector it is important to ensure:

  • The connector is mechanically robust.
  • The connector is selected according to its application.
  • The connector is rated for its application.
  • To avoid bimetallic corrosion: use a bimetallic connector (do not connect bare copper directly to bare aluminium, or have water run-off from copper fall onto aluminium).

CONDUCTOR SIZE (mm)
CONDUCTORCOLOUR
WEIGHT (kg)
PART NO.
8.0
BareBrown
0.02
PCBN08B/AD
8.0
BareGrey
0.02
PCGY08B/AD
8.0
PVC CoveredBrown
0.02
PCBN08P/AD
8.0
PVC CoveredGrey
0.02
PCGY08P/AD
8.0
PVC CoveredBlack
0.02
PCBL08P/AD
8.0
PVC CoveredStone
0.02
PCST08P/AD
8.0
PVC CoveredWhite
0.02
PCWH08P/AD
