Heavy Duty Metallic Cable Saddles

Heavy Duty Metallic Cable Saddles

SKU: HDCSxxx Category: Tag:
Clear
Download PDF

SKU: HDCSxxx Category: Tag:

Product Information:

Heavy Duty Metallic Cable Saddles are suitable for use in both Lightning Protection and Earthing Systems.

Features:

Material: High Copper Content Alloy

More Information:

Use with bare solid and stranded copper conductor or with PVC insulated copper cable.
When choosing a connector it is important to ensure:

  • The connector is mechanically robust.
  • The connector is selected according to its application.
  • The connector is rated for its application.
  • To avoid bimetallic corrosion-use a bimetallic connector (do not connect bare copper directly to bare aluminium, or have water run-off from copper, fall into aluminium).
Galvanic corrosion happens when there is a potential difference between dissimilar metals:
  • When the materials are in contact in the presence of an electrolyte, corrosion occurs. One metal becomes the anode, the other the cathode. The anode will tend to go into solution and therefore corrode. The electrolyte can be water with impurities from the air.
  • In the instance of water run-off from copper- the water carries fine copper corrosion particles which, when they drop on to aluminium or zinc, may result in corrosion. The direct contact of the dissimilar metals is not required for corrosion to occur in such a case.

Use with BARE SOLID and STRANDED COPPER:

CONDUCTOR CSA (mm²)
CONDUCTOR DIAMETER (approx mm)
CONDUCTOR TYPE
WEIGHT (kg)
PART NO.
50
8
Bare Solid Copper
0.100
HDCS08
16
5.1
Bare Stranded Copper
0.105
HDCS16
25
6.42
Bare Stranded Copper
0.105
HDCS25
35
7.56
Bare Stranded Copper
0.105
HDCS35
50
8.9
Bare Stranded Copper
0.100
HDCS50
70
10.7
Bare Stranded Copper
0.100
HDCS70
95
12.6
Bare Stranded Copper
0.107
HDCS95
120
14.21
Bare Stranded Copper
0.107
HDCS120
150
15.75
Bare Stranded Copper
0.215
HDCS150
185
17.64
Bare Stranded Copper
0.205
HDCS185
240
20.25
Bare Stranded Copper
0.300
HDCS240
300
22.68
Bare Stranded Copper
0.290
HDCS300
400
25.65
Bare Stranded Copper
0.285
HDCS400

Use with PVC INSULATED COPPER CABLE:

CONDUCTOR CSA (mm²)
CONDUCTOR DIAMETER (approx mm)
CONDUCTOR TYPE
WEIGHT (kg)
PART NO.
16
7.10
PVC Insulated Copper Cable
0.105
HDCS16INS
25
8.90
PVC Insulated Copper Cable
0.100
HDCS25INS
35
9.95
PVC Insulated Copper Cable
0.100
HDCS35INS
50
11.70
PVC Insulated Copper Cable
0.110
HDCS50INS
70
13.35
PVC Insulated Copper Cable
0.115
HDCS70INS
95
15.60
PVC Insulated Copper Cable
0.215
HDCS95INS
120
17.20
PVC Insulated Copper Cable
0.205
HDCS120INS
150
19.10
PVC Insulated Copper Cable
0.205
HDCS150INS
185
21.30
PVC Insulated Copper Cable
0.295
HDCS185INS
240
24.30
PVC Insulated Copper Cable
0.285
HDCS240INS
300
27.05
PVC Insulated Copper Cable
0.280
HDCS300INS
400
30.35
PVC Insulated Copper Cable
0.275
HDCS400INS

Fixings:
