Inspection Pit Earth Bars (for Concrete Inspection Pit)

Inspection Pit Earth Bars (for Concrete Inspection Pit)

SKU: PBARxxxx Categories: ,
Clear
Download PDF

SKU: PBARxxxx Categories: ,

Product Information:

Inspection Pit Earth Bars are used to facilitate testing of the earth electrode or earthing system.

Features:

Material: Copper/Tinned Copper
Standard: BS:EN 13601

More Information:

The Earth Bar can be fitted into slots, to provide for multiple conductor connections.

For installing earthing applications, Copper is the recommended material to use whether below or above ground.

Materials used in earthing systems must be able to:

  • withstand mechanical damage,
  • resist corrosion,
  • provide a low impedance path to earth,
  • and carry the maximum fault condition for the application/installation.

Our castings are high quality/high copper content complying with BS 7430 and BS 62561-1. Additional to our range are UL listed Copperbond earth rods and exothermic welding.

Bare Inspection Pit Earth Bars:

DESCRIPTION
SIZE (mm) L x W x T
HOLE SIZE (mm)
WEIGHT (kg)
PART NO.
5 Hole Pit Earth Bar
300 x 25 x 6
11
0.37
PBAR5
7 Hole Pit Earth Bar
300 x 25 x 6
11
0.36
PBAR7

Tinned Inspection Pit Earth Bars:

DESCRIPTION
SIZE (mm) L x W x T
HOLE SIZE (mm)
WEIGHT (kg)
PART NO.
3 Hole Pit Tinned Earth Bar
290 x 31 x 6
11
0.50
PBAR290
5 Hole Pit Tinned Earth Bar
290 x 31 x 6
11
0.49
PBAR316
