RWP Bonds (Pipe Work)

RWP Bonds (Pipe Work)

SKU: xRWBxxx Categories: , Tag:
Clear
Download PDF

SKU: xRWBxxx Categories: , Tag:

Product Information:

RWP Bonds connect flat conductor to circular objects (eg pipework and hand rails etc.) RWP Bonds are available in either gunmetal or aluminium to suit your application.

Features:

Material: Gunmetal or Aluminium (body), Stainless Steel (bolt)
Standard: BS:EN 62561-1 Class H, BS 7430
Tightening torque: 12Nm

More Information:

An important part of a Lightning Protection System (LPS) is that electrically continuous parts of a structure must be bonded into the Lightning Protection network. The purpose of this bonding is to ensure that, in the event of a lightning discharge, any sparking of flashover of the lightning current to conductive parts of the structure, for example, water pipes, cables, etc are avoided.

CONDUCTOR MATERIAL
CONDUCTOR SIZE (mm)
BOLT MATERIAL
BOLT SIZE
WEIGHT (kg)
PART NO.
Copper
25 x 3
Gunmetal
M10
0.19
CRWB
Aluminium
25 x 3
Aluminium
M10
0.09
ARWB
Copper
31 x 6
Gunmetal
M10
0.25
CRWB316
