Tower Earth Clamps

Tower Earth Clamps

SKU: TExxx Categories: , , Tag:
Clear
Download PDF

SKU: TExxx Categories: , , Tag:

Product Information:

Tower Earth Clamps are designed to bond either copper or aluminium conductor to flat metal surfaces.

Features:

Material: Copper or Aluminium (body), Brass (bolt)
Standard: BS:EN 62561-1 Class H, BS 7430
Tightening torque: 12Nm

More Information:

An important part of a Lightning Protection System (LPS) is that electrically continuous parts of a structure must be bonded into the Lightning Protection network. The purpose of this bonding is to ensure that, in the event of a lightning discharge, any sparking of flashover of the lightning current to conductive parts of the structure, for example, water pipes, cables, etc are avoided.

DESCRIPTION
CONDUCTOR SIZE RANGE (mm²)
CONDUCTOR MATERIAL
WEIGHT (kg)
PART NO.
Single Plate Clamp
25 - 50
Copper
0.08
TEC2550
Single Plate Clamp
25 - 50
Aluminium
0.06
TEA2550
Double Plate Clamp
16 - 70
Copper
0.13
TEC1670
Double Plate Clamp
70 - 120
Copper
0.23
TEC70120
