Split Bolt Connectors

Split Bolt Connectors

Clear
Download PDF

Product Information:

Split Bolt Connectors will accept a range of stranded or solid circular conductors. No specialist tools are required for installation.

Features:

Material: High Strength Copper Alloy
Standard: BS 7430

More Information:

An important part of a Lightning Protection System (LPS) is that electrically continuous parts of a structure must be bonded into the Lightning Protection network. The purpose of this bonding is to ensure that, in the event of a lightning discharge, any sparking of flashover of the lightning current to conductive parts of the structure, for example, water pipes, cables, etc are avoided.

MAIN: Minimum - Maximum (mm²)
TAP: Minimum - Maximum (mm²)
WEIGHT (kg)
PART NO.
4 - 10
2.5 - 10
0.02
SBC8
10 - 16
2.5 - 16
0.03
SBC4
16 - 25
4 - 25
0.04
SBC2
25 - 35
4 - 35
0.06
SBC1
35 - 50
4 - 50
0.09
SBC10
35 - 70
4 - 70
0.14
SBC20
50 - 95
4 - 95
0.17
SBC30
50 - 120
6 - 120
0.18
SBC40
95 - 185
6 - 185
0.35
SBC50
