Stranded Copper Cable (Green/Yellow PVC Covered)

Stranded Copper Cable (Green/Yellow PVC Covered)

SKU: CCGYxxx Categories: , Tag:
Clear
Download PDF

SKU: CCGYxxx Categories: , Tag:

Product Information:

Stranded Copper Cable (Green/Yellow PVC covered) is used as earth continuity conductors, equipment tails etc.

Features:

Material: Soft drawn stranded copper cable
Standard: BS:EN 60228 (conductor), BS 6746C (PVC colour)
Temp range: 0°C to 70°C

More Information:

Such conductors are generally referred to in the industry as 6491X, voltage rating 450/750V (designated suitable 600/1000V).

Conductors are an essential component of a Lightning Protection System. They form part of:

  • The Air Termination Network – arresting the lightning strike
  • The Down Conductor System – taking the lightning discharge to ground
  • The Earth Termination/Network – safely dissipating the lightning discharge into the ground.

Conductors are also an integral and important component of an earthing system, whether this be for a power station, sub-station, cell site, solar PV array, etc.

Conductors provide a low impedance path and they must be:

  • Correctly sized for fault current
  • Sufficiently robust to resist mechanical damage
  • Able to resist the effects of corrosion

STRANDING No./DIA (mm)**
NOMINAL DIAMETER (mm)
CSA (mm²)
WEIGHT (kg/m)
PART NO.
7 / 1.70
5.10
16
0.15
BSCW016/T
7 / 2.14
6.42
25
0.23
BSCW025/T
7 / 2.52
7.56
35
0.32
BSCW035/T
19 / 1.78
8.90
50
0.43
BSCW050/T
19 / 2.14
10.70
70
0.62
BSCW070/T
19 / 2.52
12.60
95
0.86
BSCW095/T
37 / 2.03
14.21
120
1.09
BSCW120/T
37 / 2.25
15.75
150
1.33
BSCW150/T
37 / 2.52
17.64
185
1.67
BSCW185/T
61 / 2.25
20.25
240
2.20
BSCW240/T
61 / 2.52
22.68
300
2.76
BSCW300/T
61 / 2.85
25.65
400
3.53
BSCW400/T

**Stranding may vary
