Copper Cable (Bare Stranded)

Copper Cable (Bare Stranded)

SKU: BSCWxxx Category: Tags: ,
Clear
Download PDF

SKU: BSCWxxx Category: Tags: ,

Product Information:

Copper Cable (Bare stranded) is suitable for earthing applications.

Features:

Material: Soft Drawn Stranded Copper Cable to BS:EN 60228 (can supply Hard Drawn on request to BS 7884)
Standard: BS:EN 60228

More Information:

Conductors are an essential component of a Lightning Protection System. They form part of:

  • The Air Termination Network – arresting the lightning strike
  • The Down Conductor System – taking the lightning discharge to ground
  • The Earth Termination/Network – safely dissipating the lightning discharge into the ground.

Conductors are also an integral and important component of an earthing system, whether this be for a power station, sub-station, cell site, solar PV array, etc.

Conductors provide a low impedance path and they must be:

  • Correctly sized for fault current
  • Sufficiently robust to resist mechanical damage
  • Able to resist the effects of corrosion

CSA (mm²)
STRANDING No./DIA (mm)**
NOMINAL DIAMETER (mm)
WEIGHT (kg/m)
PART NO.
6.0
7 / 1.04
3.12
0.05
BSCW006
16
7 / 1.70
5.10
0.15
BSCW016
25
7 / 2.14
6.42
0.23
BSCW025
35
7 / 2.52
7.56
0.32
BSCW035
50
19 / 1.78
8.90
0.43
BSCW050
70
19 / 2.14
10.70
0.62
BSCW070
95
19 / 2.52
12.60
0.86
BSCW095
120
37 / 2.03
14.21
1.09
BSCW120
150
37 / 2.25
15.75
1.33
BSCW150
185
37 / 2.52
17.64
1.67
BSCW185
240
61 / 2.25
20.25
2.20
BSCW240
300
61 / 2.52
22.68
2.76
BSCW300
400
61 / 2.85
25.65
3.53
BSCW400

**Stranding may vary.
