Copper Cable (Lead Covered Stranded)

Copper Cable (Lead Covered Stranded)

SKU: BSCWxxx/LS Category: Tag:
Clear
Download PDF

SKU: BSCWxxx/LS Category: Tag:

Product Information:

Copper Cable (Lead covered stranded) is used in areas where corrosion is an issue.

Features:

Material: Soft drawn stranded copper cable
Standard: BS:EN 60228
Covering: Type ‘B’ lead alloy (2mm thick coating)

More Information:

Conductors are an essential component of a Lightning Protection System. They form part of:

  • The Air Termination Network – arresting the lightning strike
  • The Down Conductor System – taking the lightning discharge to ground
  • The Earth Termination/Network – safely dissipating the lightning discharge into the ground.

Conductors are also an integral and important component of an earthing system, whether this be for a power station, sub-station, cell site, solar PV array, etc.

Conductors provide a low impedance path and they must be:

  • Correctly sized for fault current
  • Sufficiently robust to resist mechanical damage
  • Able to resist the effects of corrosion
CSA (mm²)
STRANDING NO./DIA (mm)
NOMINAL DIAMETER (mm)
WEIGHT (kg/m)
PART NO.
185
37 / 2.52
21.64
1.67
BSCW185/LS
240
61 / 2.25
24.25
2.20
BSCW240/LS
300
61 / 2.52
26.68
2.76
BSCW300/LS
400
61 / 2.85
29.65
3.53
BSCW400/LS
