Galvanised Steel Tape

Galvanised Steel Tape

SKU: GST3035 Category: Tag:

Conductor Size (X x Y) (mm): 30 x 3.5

CSA (mm²): 105

Download PDF

SKU: GST3035 Category: Tag:

Product Information:

Galvanised Steel Tape is suitable for BS:EN 62305 internal foundation earthing rings.

Features:

Material: Galvanised Steel
Standard: BS:EN 62561-2

More Information:

Conductors provide a low impedance path to earth and they must be:

  • Correctly sized for fault current
  • Sufficiently robust to resist mechanical damage
  • Able to resist the effects of corrosion
Conductors are an essential component of a Lightning Protection System. They form part of:

  • The Air Termination Network – arresting the lightning strike
  • The Down Conductor System – taking the lightning discharge to ground
  • The Earth Termination Network – safely dissipating the lightning discharge into the ground.
Conductors are also an integral and important component of an earthing system, whether this be for a power station, sub-station, cell site, solar PV array etc.
CONDUCTOR SIZE (X x Y) (mm)
CSA (mm²)
COIL SIZE (m)
WEIGHT (kg/m)
PART NO.
30 x 3.5
105
30
0.84
GST3035
