Solid Circular Copper

Solid Circular Copper

SKU: CC08 Category: Tag:

Diameter (X) (mm): 8.0

CSA (mm²): 50

Download PDF

SKU: CC08 Category: Tag:

Product Information:

Solid Circular Copper is sold in the specified coil lengths only.

Features:

Material: Copper
Standard: BS:EN 13601 (formerly BS 1432)

More Information:

Conductors are an essential component of a Lightning Protection System. They form part of:

  • The Air Termination Network – arresting the lightning strike
  • The Down Conductor System – taking the lightning discharge to ground
  • The Earth Termination/Network – safely dissipating the lightning discharge into the ground.

Conductors are also an integral and important component of an earthing system, whether this be for a power station, sub-station, cell site, solar PV array, etc.

Conductors provide a low impedance path and they must be:

  • Correctly sized for fault current
  • Sufficiently robust to resist mechanical damage
  • Able to resist the effects of corrosion
DIAMETER (X) (mm)
CSA (mm²)
COIL SIZE (m)
WEIGHT (kg/m)
PART NO.
8.0
50
50
0.44
CC08
